BSK^®-Floating Sensor Holder
Floating Sensor Holder (BSK^®- FSH 3/5)

Special Features of the BSK^®‑Sensor Holder

simple calibration of the measurement technology
low weight
easy to maintain and simple to clean
stable water position due to special shape
sensor protection
UV- and acid-resistant materials
floating attachment

With our BSK^®-Floating Sensor Holder we have developed an effective and easy-to-handle vertical floating system, which guarantees a consistent immersion depth for sensors to control and monitor the processes of a wastewater treatment plant.

Fields of Application

Our BSK^®-Floating Sensor Holder is used everywhere in wastewater treatment processes, where fluctuating water levels exist and therefore a fixed installation of sensors does not guarantee optimal process- or data measurement results.

The BSK^®-FSH is predestined for the use in SBR-plants (Sequence-Batch-Reactor). The floating attachment allows the sensors to follow the fluctuating water level, which guarantees an ideal immersion at any time.

Specification and Sizes

We can adapt our BSK^®-FSH to your specific application and the measurement technology you use.

Sizes

Our BSK^®-FSH is available in two sizes – either with 3 or 5 individual sensor slots.

Sensor Manufacturer

You have the free choice to choose. Whether Endress+Hauser, WTW or Hach Lange, the BSK®-FSH has the right adapter for every sensor manufacturer on the market.

Basin Depth

The BSK^®-FSH can be modified as required and is suitable for almost any type of tank and any water level.can be modified as required and is suitable for almost any type of tank and any water level.

Material

The float is made of robust and UV-resistant PE. All other components like holder, guide rail and fasteners are made of high-quality stainless steel (1.4301 or 1.4571). Our BSK^®-FSH can therefore also be used in in aggressive wastewater.

Accessories

Upon request, we can deliver the appropriate lifting system. This system makes it easier for every day work, especially in inaccessible areas (e.g. in confined spaces).

Advantages

Our BSK^®-Floating Sensor Holder offers the following advantages, among others:

Easy calibration of the measuring technology due to permanent accessibility
Low weight and simple installation, easy to maintain and clean
Despite its low weight, the BSK^® sensor mount is characterized by its special float shape and a stable water position
The sensitive sensors are protected by the attachment in the float and cannot damage the pool wall even in high turbulence in the clarifier (oscillation of the sensors is not possible) Even under conditions of high turbulences, the sensors cannot touch the inner tank wall (e.g. as a result of unstable oscillation)
UV- and acid-resistant materials enable the use in almost any project

Video about the floating mounting

Individual and efficient solutions for wastewater treatment

Biogest International^® – Your specialist for the planning and implementation of wastewater treatment plants worldwide
